CleanSwitch Selector - Non-Contact Door Access

SKU: 00000

£0.00 £0.00

Product Overview

Contact-free activation and locking switch for entrances. Available with programmable LED colour feedback. Many icons available, use drop downs to view options/pricing.
Order by 1pm
For same-day dispatch*
*stock levels permitting
FREE Technical Support
Mon - Fri | 8:30am - 5:00pm
Personalised Goods
Laser cutting and engraving services

Available in white or black, with or without optical feedback, and choice of 12 pictograms, blank, or no cover. Customised icons (such as company logos) possible, contact us for details.

NOTE: Versions with LED feedback can be programmed red, blue, or green. Colour animation is for demonstration purposes; can only program one colour at a time. Non-LED feedback versions have grey ring.

NEW: "CleanSwitch Lock" allows convenient locking of entrances. CLICK HERE to view brochure.

To view kits and component parts, CLICK HERE.

BBC Bircher Smart Access’ award-winning contactless switches allow contact-free door activation from distances of up to 50cm, making the new CleanSwitch ideal for settings with hygiene requirements including hospitals and catering environments.

This robust switch can be treated with standard cleaning agents and disinfectants without causing damage to its housing or internals.

See “specification” and “downloads” tabs for more information.

Technology: Microwave Doppler Radar Frequency 24.125 GHz
Detection range: 0.1 – 0.5 m
Detection mode: Pulse mode: sensor detects while hand is moving / Toggle mode: first movement on/ second movement off
Detection speed: Min: 5 Hz or ± 3 cm/s Max: 200 Hz or ± 1.2 m/s
Supply voltage: 12 – 24 VAC ± 10 % (50 – 60 Hz) 12 – 24 VDC + 20 % / – 10
Max. power consumption: < 1 W (with optical feedback)
Output: Relay with switch-over contact (free of potential)
Max. switching voltage/current: (DC): 1A up to 30V, 0.5A up to 60V
Max. switching voltage/current: (AC): 1A up to 60V, 0.5A up to 125V
Max. switching power: 30 W (DC) / 60 VA (AC
Output hold time: “Relay hold time”: 0.3 s “LED hold time”: 2 s
Storage / operation temperature: – 20 to + 60 ˚C
Protection class: IP65 (fixed with 4 screws, smooth surface)
Dimensions: (mm) 88 x 88 x 38 mm (L x W x H)
Weight: 55 g (cover)
Materials: ASA / PC


Certain downloads (such as manuals and wiring diagrams) are only available after logging in with a Trade Account.

CLICK HERE to login or CONTACT US to set up a free Trade Account.

Download Brochure Icon Download Brochure Data Sheet Icon Download Data Sheet
